EMKP+ Surface Veil Stitched Combo Mat

EMKP+ Surface Veil Stitched Combo Mat

EMKP+ Surface Veil Stitched Combo Mat

Surface Veil Stitched Combo Mat

Surface Veil Stitched Combo Mat is one layer of surface veil (fiberglass veil or polyester veil) combined with various of fiberglass fabrics, multiaxials and chopped roving layer by stitching them together. The base material can be only one layer or several layers of different combinations.  It can be mainly applied in pultrusion, resin resin transfer molding, continuous board making and other forming processes.

Product Details

Product features:

1. No chemical adhesive,the felt is soft and easy to set, with less hairiness;
2. Effectively improve the appearance of the products and increase the resin content on the surface of the products.
3. Solve the problem of easy break and wrinkle when the glass fiber surface mat is formed separately.
4. Reduce laying workload and improve production efficiency;



SPECIFICATIONS

Specification

Total weight
(gsm)

Base Fabrics

Base Fabric
(gsm)

Surface mat
Type

Surface mat
(gsm)

Stitching Yarn
(gsm)

EMK300/P60

370

EMK

300

Polyester veil

60

10

EMK450/F45

495

EMK

450

Fiberglass veil

45

10

LT1440/P45

1495

LT

1440

Polyester veil

45

10

WR600/P45

655

WR

600

Polyester vei

45

10

CF450/180/450/P40

1130

CF

1080

Polyester vei

40

10

Remark: We can customize various of layers scheme and weight according to customers' requirements, and also can customize special width.
